93S/FS-Exde1,9T. - Schniewindt Taiwan Sales

BRAND	Schniewindt
Product	93S/FS-Exde1,9T.
Internal code	IMP515211
Weight	1
Technical specification	EXPAT CSN Ex-Patronenheizkoerper 93S/FS-Exde1,9T. Leistung (kW): 1.9 +5%/-10% Spannung : 460 V 3~ CSN Ex-Patronenheizkoerper, Baureihe 93../..Exde.... T../..., entsprechend EG- Baumustepruefbescheinigung PTB 03 ATEX 1038 X. Ex- Heizkoerper dieser Baureihe dienen zur Erwaermung von Fluessigkeiten. Typ. 93S/ FS - Exde1,9T. Zuendschutzart = EX de IIC Einsatzbereich : Zone 1 und Zone 2 zul. Umgebungstemperatur :(°C) -20 bis +40°C Anschlusskopf Gesamtleistung (kW) 1,9 Anschussspannung (V) 460 Schaltung Dreieck Schutzart IP65 Betriebsbedingungen Einbaulage waagerecht Einbaulaenge (mm) 550 unbeheizte Laenge (mm) 50 Meduim : Wasser (gesch. Kreislauf) Betriebstemperatur 40 zul. min/max Temp. (°C) -20... 80°C zul. min/max Druck PS (bar g) 0.5 Heizeinsatz : keramischer Heizeinsatz Mechanischer Aufbau Flanschnorm: (DIN;ANSI) DIN DIN 2527 / EN 1092-1 Nennweite DN 50 Druckstufe PN6 Werkstoff P250GH (1.0460) Durchmesser Mantelrohr (mm) 52 MAterial Mantelrohr - Stahl Oberflaechenbelastung (W/cm2) 2.33 Rohranordnung zentriert Anschlusshaube -Stahl lackiert Kabelverschraubung M20 Thermostat / Fuehler - ohne

Please Contact Us to Order to offer competitive prices and delivery time for Schniewindt - 93S/FS-Exde1,9T. number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Taiwan Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
